Shihlin electric SC3 Series User Manual

Communication parameter group 07
PARAMETER DESCRIPTION 120
5.8.1 Shihlin protocol and Modbus protocol
 These protocols can link and communicate with upper controller through RS485 communication port of inverter for
parameter setting, monitoring, etc.
Parameter
Name
Default
Setting Range
Content
07-00
P.33
Communication
protocol selection
1
0
Modbus protocol
1
Shihlin protocol
07-01
P.36
Inverter
communication
station number
0
0～254
Maximum inverter connect number is determined by wiring
method and impedance matching. Please set its value to a
non-zero value when using Modbus protocol
07-02
P.32
Serial communication
baud rate
1
0
Baud rate: 4800bps
1
Baud rate: 9600bps
2
Baud rate: 19200bps
3
Baud rate: 38400bps
4
Baud rate: 57600bps
5
Baud rate: 115200bps
07-03
P.48
Data length
0
0
8 bit
1
7 bit
07-04
P.49
Stop bit length
0
0
1 bit
1
2 bit
07-05
P.50
Parity check selection
0
0
No parity check
1
Odd
2
Even
07-06
P.51
CR/LF selection
1
1
CR only
2
Both CR and LF
07-07
P.154
Modbus
communication format
4
0
1、7、N、2 (Modbus, ASCII)
1
1、7、E、1 (Modbus, ASCII)
2
1、7、O、1 (Modbus, ASCII)
3
1、8、N、2 (Modbus, RTU)
4
1、8、E、1 (Modbus, RTU)
5
1、8、O、1 (Modbus, RTU)
6
1、8、N、1 (Modbus, RTU)
07-08
P.52
Number of
communication retries
5
0～1000
If communication error times exceed set value of 07-08 (P.52)
and 07-10 (P.153) is set to 0, alarm OPT will be reported.
07-09
P.53
Communication
interval allowed time
99999
0～999.8s
Checking communication timeout with the set value
99999
No timeout check
07-10
P.153
Communication alarm
action
0
0
Alarm and stop freely
1
No alarm and continuing to operation
Shihlin protocol and Modbus protocol

If any communication parameter is changed, please power off and restart inverter.

SC3 series inverters offer two protocols to choose from: Shihlin protocol and Modbus protocol. Parameters
07-02(P.32), 07-01(P.36), 07-08(P.52), 07-09(P.53), 07-10(P.153) are for both protocols. Parameter
07-03(P.48)~07-06(P.51) only applies to Shihlin protocol and parameter 07-07（P.154）applies only to Modbus
protocol. Please refer to communication protocol for details.
Setting
