Shihlin electric SC3 Series User Manual

Special Adjustment Parameter Group 13
PARAMETER DESCRIPTION 156
5.12 Special Adjustment Parameter Group 13
Group
Parameter
Number
Name
Setting Range
Default
Page
13-00
P.89
Slip compensation coefficient
0～10
0
156
13-03
P.286
High frequency vibration
suppression factor
0.2K~5.5K model：0～1515
300
156
7.5K/11KF and above： 0～1515
509
5.12.1 Slip Compensation V/F
 This parameter can set the compensation frequency so that the motor running speed at the rated current can be
closer to the set speed, thereby improving the accuracy of speed control.
Parameter
Name
Default
Setting Range
Content
13-00
P.89
Slip compensation
coefficient
0
0～10
Execute slip compensation with target frequency as
standard. The quantity of compensation set to 10 is 3% of
target frequency.
Note: 1. This function is only valid under V/F control 00-21(P.300)=0.
2. At the process of slip compensation, the output frequency may be larger than the set frequency.
5.12.2 Vibration inhibition
 It is used to suppress the large fluctuation of inverter output current, large fluctuation of motor speed and motor
vibration.
Param
eter
Name
Default
Setting Range
Content
13-03
P.286
High frequency vibration
inhibition factor
300
0～1515
0.2K~5.5K model
If the motor vibrates at a higher frequency, adjust the set
value of 13-03(P.286). It is recommended to gradually
increase the set value based on the increment of 1.
509
7.5K/11KF and above
Vibration inhibition factor
 In practical applications, the frequency range where the vibration occurs is usually lower than or higher than half of
the rated frequency of the motor to distinguish as "low frequency vibration " or "high frequency vibration ",
that is:
If the rated frequency of the motor nameplate is 50Hz,
If the frequency of oscillation is lower than 25Hz, it is considered as "low frequency vibration:".
If the frequency of oscillation is higher than 25Hz, it is considered to be "high frequency vibration ".
Note: The motor current will fluctuate in a certain operating frequency band under Normal duty conditions, which may
cause slight vibration of the motor. If it does not cause application impact, it can be ignored.
Setting
