Shihlin electric SC3 Series User Manual

Digital input/ output parameter group 03
PARAMETER DESCRIPTION 86
5.4 Digital input/ output parameter group 03
Group
Parameter
Number
Name
Setting Range
Default
Page
03-00
P.83
Terminal STF
input function
0: STF(Inverter runs forward)
0
90
1: STR(Inverter runs reverse)
2: RL(Multi-speed low speed)
3: RM(Multi-speed medium speed)
4: RH(Multi-speed high speed)
5: Reserved
6: External thermal relay actuate
7: MRS(Stops inverter output immediately)
8: RT(Inverter second function)
9: EXJ(External JOG)
10：STF+EXJ
11：STR+EXJ
12：STF+RT
13：STR+RT
14：STF+RL
15：STR+RL
16：STF+RM
17：STR+RM
18：STF+RH
19：STR+RH
20：STF+RL+RM
21：STR+RL+RM
22：STF+RT+RL
23：STR+RT+RL
24：STF+RT+RM
25：STR+RT+RM
26：STF+RT+RL+RM
27：STR+RT+RL+RM
28: RUN(Inverter runs forward)
29: STF/STR(use with RUN signal, when ON, motor runs
reverse； when OFF, motor runs forward)
30: RES(External reset function)
31: STOP(Use as three line control with RUN signal and
STF-STR signal)
32: REX(Extend multi-speed to 16 levels)
33: PO(In “external mode", run programmed operation)
34: RES_E (External reset, valid only when alarm.)
35: MPO (In “external mode” run manual cycle operation.)
36: TRI(Triangle wave function)
