Basic operation steps for different modes
BASIC OPERATION 42
4.3.6
Basic operation steps for combined mode 2 (00-16(P.79)＝5)
• In Combined Mode 2, indicator in will light up.
Note: For selecting and switching the operation mode, please refer to section 4.2 Operation modes of inverter.
• Target frequency is set by external terminals (default priority from high to low):
• If the programmable operating mode is chosen, please refer to section 5.4.1 function selection of digital input and 5.5.2
programmed operation mode.
• If target frequency is set by multi-speed stage levels, please refer to section 5.5.1 16 step speed.
• If target frequency is set by input signal across terminal 3-5, please refer to section 5.3.3 terminal 3-5 signal selection
and processing.
• Press or to run the motor. At this point, indicator will flicker to indicate that the motor is running.
Note: 1. For detailed operation steps for monitoring mode, please refer to section 4.2.3.
2. While the motor is running, the user can enter frequency setting mode to change target frequency for regulating
the motor speed.
• Press and the motor will begin to decelerate until it comes to a full stop.
• Indicator in will not turn off until the inverter stops outputting voltage.
4.3.7 Basic operation steps for combined mode 3(00-16(P.79)＝6)
• In Combined Mode 3, indicator in will flicker.
Note: 1. For detailed operation procedures for monitor mode, please refer to section 4.2.
Default priority from high to low：
• When external JOG is “on”, target frequency is determined by 01-13(P.15). Acceleration / deceleration time is set by the
value of 01-14(P.16).
• When RL, RM, RH and REX of multi-speed stage levels are “on”, target frequency is determined by combination of
multi-speed stage levels, please refer to section 5.5.1 16 step speed.
• Target frequency is set by communication.
• Give STF/STR signal to run the motor. At this point, indicator will flicker to indicate that the motor is running.
• Functions of 00-02 (P.996~P.999) can be accomplished by communication.
Note: For detailed operation procedures for the monitor mode, please refer to Section 4.2.3.
• When terminal STF/STR signals turn off, motor will decelerate until it comes to a full stop.
• Indicator in will not turn off until the inverter stops outputting.
