Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 165
7. Appendix
7.1 Appendix 1 Parameter table
7.1.1 Parameter in P sequence
Parameter
Number
Group
Name
Setting Range
Default
Page
P.0
01-10
Torque boost
0.75K and under :0～30.0%
6.0%
68
1.5K~3.7K model：0～30.0%
4.0%
5.5K~7.5K/11KF model：0～30.0%
3.0%
11K/15KF and above model：0～30.0%
2.0%
P.1
01-00
Maximum frequency
0.00～01-02（P.18）Hz
120.00Hz
64
P.2
01-01
Minimum frequency
0～120.00Hz
0.00Hz
64
P.3
01-03
Base frequency
50Hz system setting: 0～650.00Hz
50.00Hz
65
60Hz system setting: 0～650.00Hz
60.00Hz
P.4
04-00
Speed 1 (high speed)
0～650.00Hz
60.00Hz
100
P.5
04-01
Speed 2 (medium speed)
0～650.00Hz
30.00Hz
100
P.6
04-02
Speed 3 (low speed)
0～650.00Hz
10.00Hz
100
P.7
01-06
Acceleration time
3.7K and below：0～360.00s/0～3600.0s
5.00s
66
5.5K model：0～360.00s/0～3600.0s
10.00s
7.5K/11KF and above model：0～360.00s/0～3600.0s
20.00s
P.8
01-07
Acceleration time
3.7K and below：0～360.00s/0～3600.0s
5.00s
66
5.5K ~7.5K/11KF model：0～360.00s/0～3600.0s
10.00s
11K/15KF and above model：0～360.00s/0～3600.0s
30.00s
P.9
06-00
Electronic thermal relay
capacity
0~500.00A
0.00A
110
P.10
10-00
DC brake operating
frequency
0～120.00Hz
3.00Hz
144
P.11
10-01
DC brake operating time
0～60.0s
0.5s
144
P.12
10-02
DC brake operating
voltage
7.5K/11KF and below model：0～30.0%
4.0%
144
11K/15KF and above model：0～30.0%
2.0%
P.13
01-11
Starting frequency
0～60.00Hz
0.50Hz
68
P.14
01-12
Load pattern selection
0: For constant torque loads (conveyor belt, etc.)
0
69
1: For variable torque loads (fans and pumps, etc.)
2～3：For Lifting loads
4: Multipoint V/F curve
5~13: Special two-point V/F curve
P.15
01-13
JOG frequency
0～650.00Hz
5.00Hz
71
P.16
01-14
JOG Acc/ Dec time
0～360.00s/0～3600.0s
0.50s
71
P.17
02-20
Terminal 3-5 signal range
selection
0: Signal sampling range from 4~20mA.
1
80
1: Signal sampling range from 0～10V.
2: Signal sampling range from 0～5V.
P.18
01-02
High-speed maximum
frequency
01-00（P.1）～650.00Hz
120.00Hz
64
