Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 166
Parameter
Number
Group
Name
Setting Range
Default
Page
P.19
01-04
Base voltage
0～1000.0V
99999
65
99999：Change according to the input voltage
P.20
01-09
Acceleration/deceleration
reference frequency
50Hz system setting: 1.00～650.00Hz
50.00Hz
66
60Hz system setting: 1.00～650.00Hz
60.00Hz
P.21
01-08
Acceleration/deceleration
time increments
0: Time increment is 0.01s
0
66
1: Time increment is 0.1s
P.22
06-01
Stall prevention operation
level
0～250.0%
150.0%
111
P.23
06-02
Stall prevention operation
level correction factor
0～200.0%
99999
111
99999: Stall prevention operation level is the setting
value of 06-01(P.22).
P.24
04-03
Speed 4
0～650.00Hz
99999
100
99999: Off
P.25
04-04
Speed 5
Same as 04-03
99999
100
P.26
04-05
Speed 6
Same as 04-03
99999
100
P.27
04-06
Speed 7
Same as 04-03
99999
100
P.28
01-15
Output frequency filter time
0～31
0
72
P.29
01-05
Acceleration/deceleration
curve selection
0: Linear acceleration /deceleration curve
0
66
1: S shape acceleration /deceleration curve 1
2: S shape acceleration /deceleration curve 2
3: S shape acceleration /deceleration curve 3
P.30
06-05
Regenerative brake
selection
0: Brake duty is fixed at 3%, parameter 06-06(P.70)
will be off.
0
112
1: Brake duty is 06-06(P.70) value.
P.31
00-12
Soft-PWM carrier function
selection
0: Off
0
57
1: When 00-11(P.72)<5,Soft-PWM is on(only apply
to V/F control)
2：When 00-11(P.72)＞9, if the IGBT temperature is
higher than 60°c, carrier frequency will decrease
automatically, when temperature go back to under
40°c, carrier frequency go back to 00-11(P.72)
value.
P.32
07-02
Serial communication baud
rate
0：baud rate :4800bps
1
120
1：baud rate :9600bps
2：baud rate :19200bps
3：baud rate :38400bps
4：baud rate :57600bps
5：baud rate :115200bps
P.33
07-00
Communication protocol
selection
0：Modbus protocol
1
120
1：Shihlin protocol
P.34
07-11
Communication EEPROM
write-in selection
0：When writing parameters through communication,
write in RAM and EEPROM
0
135
1：When writing parameters through communication,
only write into RAM
