Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 167
Parameter
Number
Group
Name
Setting Range
Default
Page
P.35
00-19
Communication mode
selection
0: In communication mode, run signal and frequency
is given by communication.
0
59
1: In communication mode, run signal and frequency
is given by external signal.
P.36
07-01
Inverter communication
station number
0～254
0
120
P.37
00-08
Speed display
0：Display output frequency(not mechanical speed)
0.0
55
0.1~5000.0
1~50000
P.39
02-21
Terminal 3-5 maximum
operation frequency
50Hz system:1.00～650.00Hz
50.00Hz
80
60Hz system:1.00～650.00Hz
60.00Hz
P.41
03-20
Output frequency detection
sensitivity
0～100.0%
10.0%
95
P.42
03-21
Output frequency detection
for forward rotation
0～650.00Hz
6.00Hz
95
P.43
03-22
Output frequency detection
for reverse rotation
0～650.00Hz
99999
95
99999: Same as the setting of 03-21(P.42)
P.44
01-22
Second acceleration time
0～360.00s/0～3600.0s
99999
74
99999：Off
P.45
01-23
Second deceleration time
0～360.00s/0～3600.0s
99999
74
99999：Off
P.46
01-24
Second torque boost
0～30.0%
99999
74
99999：Off
P.47
01-25
Second base frequency
0～650.00Hz
99999
74
99999：Off
P.48
07-03
Data length
0：8bit
0
120
1：7bit
P.49
07-04
Stop bit length
0：1bit
0
120
1：2bit
P.50
07-05
Parity check selection
0：No parity check
0
120
1：Odd
2：Even
P.51
07-06
CR/LF selection
1: CR only
1
120
2：Both CR and LF
P.52
07-08
Number of communication
retries
0～1000
5
120
P.53
07-09
Communication interval
allowed time
0～999.8s：Check communication timeout with the
set value
99999
120
99999：No timeout check
P.56
02-52
Inverter rated current
display level
0~500.00A
According
to model
85
P.57
10-09
Restart idling time
0～30.0s
99999
146
99999: Off.
P.58
10-10
Restart rising time
7.5K/11KF and below model : 0～60.0s
5.0s
146
11K/15KF and above model : 0～60.0s
10.0s
