Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 168
Parameter
Number
Group
Name
Setting Range
Default
Page
P.59
00-10
Built-in keypad set target
frequency selection
XXX0: Use wheel on built-in keypad or external
keypad to set frequency
0
59
XXX1: Use keypad knob on external keypad to set
frequency
X0XX: Frequency change done and setting saves in
30 seconds
X1XX: Frequency change done and setting saves in
10 seconds
X2XX: Every frequency change will not save
0XXX: Set frequency will work immediately when
use wheel on built-in keypad
1XXX: Set frequency will work after pressing SET
when use wheel on built-in keypad
P.60
02-10
Terminal 3-5 filter time
0～2000ms
31
80
P.61
10-11
Remote control function
0: Off
0
147
X1 ： Remote control function, frequency save in
memory
X2：Remote control function, frequency won’t save
X3：Remote control function, frequency won’t save,
clear frequency setting every time STF/STR “turn
off”.
X4: Remote control function, frequency save in
memory every 5s
1X:Frequency command range 01-01(P.2)~01-00
(P.1), frequency command value from RH,RM
setting
P.62
03-23
Zero current detection level
0～200.0%
5.0%
96
99999: Off
P.63
03-24
Zero current detection time
0.05～100.00s
0.50s
96
99999: Off
P.65
10-12
Auto reset function
0: Off.
0
149
1: When over-voltage, inverter will reset.
2: When over-current, inverter will reset.
3: When either over-voltage or over-current, inverter
will reset.
4: When any alarm occurs, inverter will reset.
P.66
06-03
Stall prevention operation
reduction starting frequency
50Hz system:0～650.00Hz
50.00Hz
111
60Hz system:0～650.00Hz
60.00Hz
P.67
10-13
Auto reset times
0: Off.
0
149
1 ～ 10: If the alarm exceeds 10-13(P.67) times,
inverter will not reset.
P.68
10-14
Auto reset waiting time
0～360.0s
6.0s
149
P.69
10-15
Auto reset times count
Read only
0
149
