Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 169
Parameter
Number
Group
Name
Setting Range
Default
Page
P.70
06-06
Special regenerative brake
duty
0～100.0%
0.0%
112
P.71
00-13
Idling brake / DC brake
0: Idling brake
1
58
1: DC brake
P.72
00-11
Carrier frequency
11K/15KF and below model：1~15kHz
5kHz
57
15K/18.5KF and above Heavy Duty：1~15kHz
15K/18.5KF and above Normal Duty：1~10kHz
P.75
00-14
Stop function selection
0: Press STOP button and inverter stop running in
PU and H2 mode
1
58
1: Press STOP button and inverter stop running in all
mode.
P.77
00-03
Selection of parameters write
protection
0: Parameters can be written only when the motor
stops.
0
52
1: Parameters cannot be written.
2: Parameters can also be written when the motor is
running.
3: Parameters cannot be read when in password
protection.
P.78
00-15
Prevent forward/reverse
rotation selection
0: Forward/reverse rotation are both permitted.
0
59
1: Prevent reverse rotation (Giving reverse signal
decelerates and stops the motor).
2: Prevent forward rotation (Giving forward signal
decelerates and stops the motor).
P.79
00-16
Operation mode selection
0: “PU mode”, “external mode” and “Jog mode” are
interchangeable.
0
59
1: “PU mode” and “JOG mode” are interchangeable.
2: “External mode” only
3: “Communication mode” only
4: “Combined mode 1”
5: “Combined mode 2”
6: “Combined mode 3”
7: “Combined mode 4”
8: “Combined mode 5”
P.80
03-03
Terminal M0 input function
Same as 03-00
2
90
P.81
03-04
Terminal M1 input function
Same as 03-00
3
90
P.83
03-00
Terminal STF
input function
0: STF(Inverter runs forward)
0
90
1: STR(Inverter runs reverse)
2: RL(Multi-speed low speed)
3: RM(Multi-speed medium speed)
4: RH(Multi-speed high speed)
5: Reserved
6: External thermal relay actuate
7: MRS(Stops inverter output immediately)
8: RT(Inverter second function)
9: EXJ(External JOG)
