Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 170
Parameter
Number
Group
Name
Setting Range
Default
Page
P.83
03-00
Terminal STF
input function
10：STF+EXJ
0
90
11：STR+EXJ
12：STF+RT
13：STR+RT
14：STF+RL
15：STR+RL
16：STF+RM
17：STR+RM
18：STF+RH
19：STR+RH
20：STF+RL+RM
21：STR+RL+RM
22：STF+RT+RL
23：STR+RT+RL
24：STF+RT+RM
25：STR+RT+RM
26：STF+RT+RL+RM
27：STR+RT+RL+RM
28: RUN(Inverter runs forward)
29: STF/STR(use with RUN signal, when ON, motor runs
reverse； when OFF, motor runs forward)
30: RES(External reset function)
31: STOP(Use as three line control with RUN signal and
STF-STR signal)
32: REX(Extend multi-speed to 16 levels)
33: PO(In “external mode", run programmed operation)
34: RES_E (External reset, valid only when alarm.)
35: MPO (In “external mode” run manual cycle operation.)
36: TRI(Triangle wave function)
37~38：Reserved
39: STF/STR +STOP (Use with RUN signal, when ON, motor
runs reverse, when OFF, motor stops then runs forward.)
40: P_MRS (Stops inverter output immediately by pulse
signal input)
41~42：Reserved
43: RUN_EN (Enable digital input terminal operation)
44: PID_OFF (Enable digital input terminal turning off PID)
45: Second frequency command source mode
46~91：Reserved
92：Fire mode command 1(RUN command included)
93：Fire mode command 2(RUN command excluded)
P.84
03-01
Terminal STR
input function
Same as 03-00
1
90
