Appendix 1 Parameter table
Appendix 171
Terminal A-C output
function
0: RUN(Output when inverter running)
1: SU(Output when reach target frequency)
2: FU(Output when reach 03-21 03-22 value )
3: OL(Output when overload)
4: OMD(Output when output current is zero)
5: ALARM(Output when alarm)
6: PO1(Output when in program operation step)
7: PO2(Output when in program operation cycle)
8: PO3(Output when in program operation pause)
11:OMD1(Output when output current is zero 1)
12 :OL2(Output when over torque)
17: RY(Output when inverter is powered on and no
alarm)
18: Output when it’s time for maintenance
41:PID feedback disconnection (AErr) alarm
0:Terminal A-C output positive logic
2:Terminal A-C output negative logic
Slip compensation
coefficient
Second target frequency
selection
0: Frequency set by built-in keypad
1: Frequency set by RS485 communication
2: Frequency set by analog input
Output voltage 1 of
middle frequency
