Appendix 1 Parameter table
Appendix 172
Programmed operation minute /
second selection
0: Select minute as the time increment.
1: Select second as the time increment.
Programmed operation mode
speed 1 operating time
Programmed operation mode
speed 2 operating time
Programmed operation mode
speed 3 operating time
Programmed operation mode
speed 4 operating time
Programmed operation mode
speed 5 operating time
Programmed operation mode
speed 6 operating time
Programmed operation mode
speed 7 operating time
Programmed operation mode
speed 8 operating time
Built-in keypad monitor selection
X0：When inverter starts, built-in keypad enters
monitor mode automatically, screen displays
output frequency (with slip compensation ).
X1 ： When inverter starts, built-in keypad
displays target frequency.
X2：When inverter starts, built-in keypad enters
monitor mode automatically, screen displays
steady state output frequency
X3：When inverter starts, built-in keypad enters
monitor mode automatically, screen displays
current pressure and feedback pressure of the
constant pressure system in percentage
X4：When inverter starts, built-in keypad
doesn’t enter monitor mode but enter the
previous mode before power off
X5：When inverter starts, built-in keypad enters
monitor mode automatically, screen displays
current pressure and feedback pressure of the
constant pressure system
4X：When the inverter is standby, the keypad
goes into target frequency mode automatically
and figure blinks on the keypad panel
Programmed operation mode
speed 1 Acc/Dec time
