Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 173
Parameter
Number
Group
Name
Setting Range
Default
Page
P.112
04-36
Programmed operation mode speed 2
Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
P.113
04-37
Programmed operation mode speed 3
Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
P.114
04-38
Programmed operation mode speed 4
Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
P.115
04-39
Programmed operation mode speed 5
Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
P.116
04-40
Programmed operation mode speed 6
Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
P.117
04-41
Programmed operation mode speed 7
Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
P.118
04-42
Programmed operation mode speed 8
Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
P.119
10-16
Forward and reverse rotation dead time
0～3000.0s
0.0s
150
P.120
03-16
Output signal delay time
0～3600.0s
0.0s
94
P.121
04-16
Run direction in each section
0～255
0
102
P.122
04-17
Programmed operation cycle selection
0:Off
0
102
1～8: Start cycle from the set section.
P.123
04-18
Programmed operation acceleration /
deceleration time setting selection
0: Acceleration time is 01-06(P.7),
deceleration time is 01-07(P.8).
0
102
1: Acceleration and deceleration time
is set by 04-35(P.111)～04-42(P.118).
P.131
04-19
Programmed operation mode speed 1
0～650.00Hz
0.00Hz
102
P.132
04-20
Programmed operation mode speed 2
0～650.00Hz
0.00Hz
102
P.133
04-21
Programmed operation mode speed 3
0～650.00Hz
0.00Hz
102
P.134
04-22
Programmed operation mode speed 4
0～650.00Hz
0.00Hz
102
P.135
04-23
Programmed operation mode speed 5
0～650.00Hz
0.00Hz
102
P.136
04-24
Programmed operation mode speed 6
0～650.00Hz
0.00Hz
102
P.137
04-25
Programmed operation mode speed 7
0～650.00Hz
0.00Hz
102
P.138
04-26
Programmed operation mode speed 8
0～650.00Hz
0.00Hz
102
P.141
02-61
Polarity of percentage corresponds to
terminal 3-5 current/ voltage signal
0~11
0
80
P.142
04-07
Speed 8
Same as 04-03
0.00Hz
100
P.143
04-08
Speed 9
Same as 04-03
99999
100
P.144
04-09
Speed 10
Same as 04-03
99999
100
P.145
04-10
Speed 11
Same as 04-03
99999
100
P.146
04-11
Speed 12
Same as 04-03
99999
100
P.147
04-12
Speed 13
Same as 04-03
99999
100
P.148
04-13
Speed 14
Same as 04-03
99999
100
P.149
04-14
Speed 15
Same as 04-03
99999
100
