Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 174
Parameter
Number
Group
Name
Setting Range
Default
Page
P.150
10-08
Restart mode selection
X0：No frequency search.
0
146
X1：Reserved
X2：Decrease voltage mode
0X：Power on once.
1X：Start each time.
2X：Only instantaneous stop and restart
3X：Only valid when the inverter resets in fire mode
P.151
10-03
Zero-speed control function
selection
0: Off.
0
145
1: DC voltage braking
P.152
10-04
Voltage at zero-speed control
7.5K/11KF and below model：0～30.0%
5.0%
145
11K/15KF and above model：0～30.0%
2.0%
P.153
07-10
Communication alarm action
0：Alarm and stop freely
0
120
1：No alarm and continuing to operation
P.154
07-07
Modbus communication format
0：1、7、N、2 (Modbus, ASCII)
4
120
1：1、7、E、1 (Modbus, ASCII)
2：1、7、O、1 (Modbus, ASCII)
3：1、8、N、2 (Modbus, RTU)
4：1、8、E、1 (Modbus, RTU)
5：1、8、O、1 (Modbus, RTU)
6：1、8、N、1 (Modbus, RTU)
P.155
06-08
Over torque detection level
0～200.0%
0.0%
113
P.156
06-09
Over torque detection time
0～60.0s
1.0s
113
P.157
03-17
Digital input terminal filter time
0～2000
4
94
P.158
03-18
Digital input terminal enable
when power on
0: When power on digital terminals work directly
0
95
1: When power on digital terminals work after
switch off then on
P.159
10-17
Energy-saving control function
0: Off.
0
150
1: Energy-saving mode.
P.161
00-07
Multi-function display
0: Output AC voltage (V)
0
54
1: DC bus voltage. (V)
2: Inverter temperature rising accumulation rate
(%)
3: Target pressure of the constant pressure system
(%)
4: Feedback pressure of the constant pressure
system (%)
5: Running frequency (Hz)
6: Electronic thermal accumulation rate (%)
7：Reserved
8: Signal value (mA) of 3-5 input terminals (mA/V).
9：Output power (kW)
