Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 175
Parameter
Number
Group
Name
Setting Range
Default
Page
P.161
00-07
Multi-function display
11: Forward reverse rotation signal.
Built-in keypad: Frd is forward，rEv is
reverse，STOP is not operating status.
External keypad:1 is forward , 2 is reverse, 0
is not operating status..
0
54
12: NTC temperature (℃)
13：Motor electronic thermal accumulation
rate (%)
14~18：Reserved
19: Digital terminal input state
20: Digital terminal output state
21: Actual working carrier frequency
P.162
01-28
Middle frequency 2
0～650.00Hz
99999
75
99999：Off
P.163
01-29
Output voltage 2 of middle frequency
0～100.0%
0.0%
75
P.164
01-30
Middle frequency 3
0～650.00Hz
99999
75
99999：Off
P.165
01-31
Output voltage 3 of middle frequency
0～100.0%
0.0%
75
P.166
01-32
Middle frequency 4
0～650.00Hz
99999
75
99999：Off
P.167
01-33
Output voltage 4 of middle frequency
0～100.0%
0.0%
75
P.168
01-34
Middle frequency 5
0～650.00Hz
99999
75
99999：Off
P.169
01-35
Output voltage 5 of middle frequency
0～100.0%
0.0%
75
P.170
08-00
PID function selection
0: Off
0
137
2：Parameter 08-03(P.225) as target value,
terminal 3-5 current/voltage input as
feedback source
3：Target value is set by multi-speed value,
and feedback from terminal 3-5
current/voltage input
P.171
08-01
PID feedback control method
0: Negative feedback control.
0
137
1: Positive feedback control.
P.172
08-04
Proportional gain
1~100
20
137
P.173
08-05
Integral time
0～100.0s
1.0s
137
P.174
08-06
Differential time
0～1000ms
0ms
137
P.175
08-07
Abnormal deviation
0～200.0%
0.0%
137
P.176
08-08
Abnormal duration time
0～600.0s
30.0s
137
P.177
08-09
Abnormal processing mode
0: Stop freely
0
137
1: Slow down to stop
2: Alarm and continue operation
P.178
08-10
Sleep detection deviation
0～100.0%
0.0%
137
P.179
08-11
Sleep detection duration time
0～255.0s
1.0s
138
