Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 176
Parameter
Number
Group
Name
Setting Range
Default
Page
P.180
08-12
Wake-up level
0～200.0%
90.0%
138
P.181
08-13
Stop level
0～120.00Hz
40.00Hz
138
P.182
08-14
Upper integral limit
50Hz system:0～120.00Hz
50.00Hz
138
60Hz system:0～120.00Hz
60.00Hz
P.183
08-15
Deceleration step length when
stable
0～10.00Hz
0.50Hz
138
P.184
02-24
Terminal 3-5 disconnect
selection
0: Off
0
80
1: Inverter decelerates to 0Hz, multi-function digital
output terminal set off alarm
2: Inverter stops immediately, and keypad displays
“AErr” alarm
3: Inverter runs continuously according to the
frequency command before disconnection. Digital
output terminal will set off alarm.
P.185
02-06
Proportional linkage gain
0～100%
0%
78
P.186
00-23
Motor types selection
0: Normal Duty (ND), on fan and pump duty type.
1
60
1: Heavy Duty (HD), apply to other duties.
P.188
00-01
Firmware version
Read only
---
49
P.189
00-24
50Hz/60Hz switch selection
0: Frequency related parameter default value is
60Hz.
0
61
1: Frequency related parameter default value is
50Hz.
1
P.196
02-27
Percentage corresponds to
terminal 3-5 minimum input
current/ voltage
0%～100.0%
0.0%
80
P.197
02-28
Percentage corresponds to
terminal 3-5 maximum input
current/ voltage
0%～100.0%
100.0%
80
P.198
02-25
Terminal 3-5 minimum input
current/ voltage
0～20.00 mA /V
0.00V
80
P.199
02-26
Terminal 3-5 maximum input
current/ voltage
0～20.00 mA/ V
10.00V
80
P.207
06-84
Fire Mode
XXX0:Invalid( fire mode is forbidden( normal
mode))
0
117
XXX1:Forward operation(the inverter runs forward
in fire mode)
XXX2:Reverse operation(the inverter runs
reversely in fire mode)
0XXX:Manually exit fire mode 1: if the start fire
mode terminal is OFF, the inverter need reset
manually and back to normal mode
1XXX:Exit fire mode automatically: if the start fire
mode terminal is OFF, the inverter goes to normal
mode automatically
2XXX:Manually exit fire mode 2 :if the start fire
mode terminal is OFF, the inverter keeps running,
need reset manually and back to normal mode
