PID parameter group 08
PARAMETER DESCRIPTION 138
Parameter
Name
Default
Setting Range
Content
08-10
P.178
Sleep detection
deviation
0.0%
0～100.0%
---
08-11
P.179
Sleep detection
duration time
1.0s
0～255.0s
---
08-12
P.180
Wake-up level
90.0%
0～200.0%
---
08-13
P.181
Stop level
40.00Hz
0～120.00Hz
---
08-14
P.182
Upper integral limit
50.00Hz
0～120.00Hz
50Hz
When the deviation value accumulated by
integral time, need to set an upper limit for
deviation accumulation. For example, the upper
integral limit of frequency is equal to 01-03(P.3) *
08-14(P.182)
60.00Hz
60Hz
08-15
P.183
Deceleration step
length when stable
0.50Hz
0～10.00Hz
When feedback pressure reach stopping deviation value
and time (in seconds), inverter will decrease frequency by
08-15 (P.183) value per second
08-18
P.223
Analog feedback
signal bias
0.0%
0～100.0%
Feedback signal correction，unify inverter feedback terminal
and actual feedback signal to make inverter and display
value the same
08-19
P.224
Analog feedback
signal gain
100.0%
0～100.0%
PID parameter group
 Calibration instructions for the offset and gain of the analog feedback signal:
1. The user does not connect the feedback signal for correction, the corresponding relationship is as follows:
3-5 input analog voltage signal
3-5 input analog current signal
Correction voltage
Correction ratio
Correction current
Correction ratio
0.1V
08-18(P.223)
4mA
08-18(P.223)
5V
08-19(P.224)
20mA
08-19(P.224)
Note: 1. The default setting corresponds to a range of 0.1~5V. If it does not match the range needed, please set
08-18 (P.223) and 08-19 (P.224). Also need to set 08-00 (P. 170)at the end to achieve uniform range.
2. To use terminal 3-5 as the PID feedback source, be sure to set 02-20 (P.17) and AVI-ACI switch first, to select
the voltage/current for terminal 3-5 signal.
Example 1：Use 0~7V for feedback signal on terminal 3-5
08-18(P.223) = 0.1 / 7 * 100.0 = 1.4
08-19(P.224) = 5 / 7 * 100.0 = 71.4
After setting 08-18 (P.223) and 08-19 (P.224) according to the above calculated value, set 08-00 (P.170)=2,
then the range after calibration is 0~7V.
Example 2: Use 0~20mA for feedback signal on terminal 3-5
08-18(P.223) = 4 / 20 * 100.0 = 20.0
08-19(P.224) = 20 / 20 * 100.0 = 100.0
After setting 08-18 (P.223) and 08-19 (P.224) according to the above calculated value, set 08-00 (P.170)=2,
then the range after calibration is 0~20mA.
