Application parameter group 10
PARAMETER DESCRIPTION 142
5.10 Application parameter group 10
Group
Parameter
Number
Name
Setting Range
Default
Page
10-00
P.10
DC brake operating
frequency
0～120.00Hz
3.00Hz
144
10-01
P.11
DC brake operating time
0～60.0s
0.5s
144
10-02
P.12
DC brake operating voltage
7.5K/11KF and below model：0～30.0%
4.0%
144
11K/15KF and above model：0～30.0%
2.0%
10-03
P.151
0～30.0%
0: Off.
0
145
1: DC voltage braking
10-04
P.152
Voltage at zero-speed
control
7.5K/11KF and below modell：0～30.0%
5.0%
145
11K/15KF and above model：0～30.0%
2.0
10-05
P.242
DC brake before inverter
start
0: Off
0
145
1: Before starting operate DC brake first.
10-06
P.243
DC brake time before
inverter start
0～60.0s
0.5s
145
10-07
P.244
DC brake voltage before
inverter start
7.5K/11KF and below model：0～30.0%
4.0%
145
11K/15KF and above model：0～30.0%
2.0%
10-08
P.150
Restart mode selection
X0：No frequency search.
0
146
X1：Reserved
X2：Decrease voltage mode
0X：Power on once.
1X：Start each time.
2X：Only instantaneous stop and restart
3X：Only valid when the inverter resets in fire mode
10-09
P.57
Restart idling time
0～30.0s
99999
146
99999: Off.
10-10
P.58
Restart rising time
7.5K/11KF and below model：0～60.0s
5.0s
146
11K/15KF and above model：0～60.0s
10.0s
10-11
P.61
Remote control function
0: Off
0
147
X1：Remote control function, frequency save in
memory
X2：Remote control function, frequency won’t save
X3：Remote control function, frequency won’t save,
clear frequency setting every time STF/STR “turn off”.
X4: Remote control function, frequency save in
memory every 5s
1X:Frequency command range 01-01(P.2)~01-00
(P.1), frequency command value from RH,RM setting
10-12
P.65
Auto reset function
0: Off.
0
149
1: When over-voltage, inverter will reset.
2: When over-current, inverter will reset.
3: When either over-voltage or over-current, inverter
will reset.
4: When any alarm occurs, inverter will reset.
