Digital input/ output parameter group 03
PARAMETER DESCRIPTION 97

If 03-21(P.42)=30 and 03-22(P.43)=20, FU signal will output when forward rotation frequency exceeds 30Hz; and
when reverse rotation frequency exceeds 20Hz, FU signal will also be output.

If 03-21(P.42)=30 and 03-22(P.43)=99999 (default), FU signal will output when forward and reverse rotation
frequency exceed 30Hz.
A-C
Output
frequency
（Hz）
Output
signal
OFF OFFON
Times
03-21(P.42)
03-22(P.43)
ON
OFF
Forward
Reverse
Note: SU and FU mentioned in this paragraph are the function names for A-C digital output. Please refer to
03-11(P.85) for details, and section 3.7 Terminal wire arrangement.
5.4.8 Zero current detection
 Detects output current level and send signal to digital output terminal.
Parameter
Name
Default
Setting Range
Content
03-23
P.62
Zero current detection
level
5.0%
0～200.0%
---
99999
Off
03-24
P.63
Zero current detection
time
0.50s
0.05～100.00s
---
99999
Off
Zero current detection

Assume inverter is fully loaded at rated value and current is 20A, set 03-23(P.62)=5% and 03-24(P.63)=0.5s,
terminal function OMD will output signal when output current is less than 20×5%=1A and exceeds 0.5s, as shown
below figure:
100%
03-23P.62
Output current
󴘠

󴘡
Time
Output
OMD
Inverter full load current level
Time
03-24P.63 03-24P.63
 If set 03-23(P.62) or 03-24(P.63) to 99999, zero current detection function is off.
Note: In this paragraph, OMD mentioned in this paragraph are the function names for digital output. Please refer to
03-11(P.85) for details, and section 3.7 Terminal wire arrangement.
Setting
