Shihlin electric SC3 Series User Manual

Basic Parameter Group 01
PARAMETER DESCRIPTION 62
5.2 Basic Parameter Group 01
Group
Parameter
Number
Name
Setting Range
Default
Page
01-00
P.1
Maximum frequency
0.00～01-02（P.18）Hz
120.00Hz
64
01-01
P.2
Minimum frequency
0～120.00Hz
0.00Hz
64
01-02
P.18
High-speed maximum
frequency
01-00（P.1）～650.00Hz
120.00Hz
64
01-03
P.3
Base frequency
50Hz system setting: 0～650.00Hz
50.00Hz
65
60Hz system setting: 0～650.00Hz
60.00Hz
01-04
P.19
Base voltage
0～1000.0V
99999
65
99999：Change according to the input voltage
01-05
P.29
Acceleration/deceleration
curve selection
0: Linear acceleration /deceleration curve
0
66
1: S shape acceleration /deceleration curve 1
2: S shape acceleration /deceleration curve 2
3: S shape acceleration /deceleration curve 3
01-06
P.7
Acceleration time
3.7K and below model：0～360.00s/0～3600.0s
5.00s
66
5.5K model：0～360.00s/0～3600.0s
10.00s
7.5K/11KF and above model：0～360.00s/0～
3600.0s
20.00s
01-07
P.8
Deceleration time
3.7K and below model：0～360.00s/0～3600.0s
5.00s
66
5.5K~7.5K/11KF model：0～360.00s/0～3600.0s
10.00s
11K/15KF and above model：0～360.00s/0～
3600.0s
30.00s
01-08
P.21
Acceleration/deceleration
time increments
0: Time increment is 0.01s
0
66
1: Time increment is 0.1s
01-09
P.20
Acceleration/deceleration
reference frequency
50Hz system setting: 1.00～650.00Hz
50.00Hz
66
60Hz system setting: 1.00～650.00Hz
60.00Hz
01-10
P.0
Torque boost
0.75K and under :0～30.0%
6.0%
68
1.5K~3.7K model：0～30.0%
4.0%
5.5K~7.5K/11KF model：0～30.0%
3.0%
11K/15KF and above model： 0～30.0%
2.0%
01-11
P.13
Starting frequency
0～60.00Hz
0.50Hz
68
01-12
P.14
Load pattern selection
0: For constant torque loads (conveyor belt, etc.)
0
69
1: For variable torque loads (fans and pumps,
etc.)
2～3：For Lifting loads
4: Multipoint V/F curve
5~13: Special two-point V/F curve
01-13
P.15
JOG frequency
0～650.00Hz
5.00Hz
71
01-14
P.16
JOG Acc/ Dec time
0～360.00s/0～3600.0s
0.50s
71
01-15
P.28
Output frequency filter time
0～31
0
72
01-16
P.91
Frequency jump 1A
0～650.00Hz
99999
72
99999：Off
01-17
P.92
Frequency jump 1B
0～650.00Hz
99999
72
99999：Off
