Shihlin electric SC3 Series User Manual

Analog input and output parameter group 02
PARAMETER DESCRIPTION 78
5.3 Analog input and output parameter group 02
Group
Parameter
Number
Name
Setting Range
Default
Page
02-06
P.185
Proportional linkage gain
0～100%
0%
79
02-07
P.240
Auxiliary frequency
0: Off
0
79
2: Output frequency = basic frequency + auxiliary
frequency (given by terminal 3-5)
4: Output frequency = basic frequency - auxiliary
frequency (given by terminal 3-5)
6: Output frequency = proportional linkage signal
(given by terminal 3-5)
02-10
P.60
Terminal 3-5 filter time
0～2000ms
31ms
80
02-20
P.17
Terminal 3-5 signal range
selection
0: Signal sampling range from 4~20mA.
1
80
1: Signal sampling range from 0～10V.
2: Signal sampling range from 0～5V.
02-21
P.39
Terminal 3-5 maximum
operation frequency
50Hz system:1.00～650.00Hz
50.00Hz
80
60Hz system:1.00～650.00Hz
60.00Hz
02-24
P.184
Terminal 3-5 disconnect
selection
0: Off
0
80
1: Inverter decelerates to 0Hz, multi-function digital
output terminal set off alarm
2: Inverter stops immediately, and keypad displays
“AErr” alarm
3: Inverter runs continuously according to the
frequency command before disconnection. Digital
output terminal will set off alarm.
02-25
P.198
Terminal 3-5 minimum input
current/ voltage
0～20.00 mA /V
0.00V
80
02-26
P.199
Terminal 3-5 maximum input
current/ voltage
0～20.00 mA/ V
10.00V
80
02-27
P.196
Percentage corresponds to
terminal 3-5 minimum input
current/ voltage
0%～100.0%
0.0%
80
02-28
P.197
Percentage corresponds to
terminal 3-5 maximum input
current/ voltage
0%～100.0%
100.0%
80
02-52
P.56
Inverter rated current display
level
0~500.00A
According
to model
85
02-61
P.141
Polarity of percentage
corresponds to terminal 3-5
current/ voltage signal
0~11
0
80
