Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 177
Parameter
Number
Group
Name
Setting Range
Default
Page
P.208
06-85
Frequency setting in fire mode
0~650.00Hz
60.00Hz
117
P.209
06-88
Accumulated times in fire
mode
Read only
Read
only
117
P.219
01-40
Remote function acc/dec time
selection
0：Use default acc/dec time（same as regular
mode）
0
77
1：Use second acc/dec time
P.223
08-18
Analog feedback signal bias
0～100.0%
0.0%
138
P.224
08-19
Analog feedback signal gain
0～100.0%
100.0%
138
P.225
08-03
PID target value from keypad
0～08-43(P.251)
20.0%
137
P.226
10-55
Reciprocating machine
function selection
0：Off
0
153
1：Turn on reciprocating machine function
P.227
10-56
Reciprocating forward limit
time
0~3600.0s
0.0s
153
P.228
10-57
Reciprocating reverse limit
time
0~3600.0s
0.0s
153
P.229
10-18
Dwell function selection
0: Off.
0
151
1: Backlash compensation function.
2: Acceleration and deceleration interrupt waiting
function.
P.230
10-19
Dwell frequency at
acceleration
0～650.00Hz
1.00Hz
151
P.231
10-20
Dwell time at acceleration
0～360.0s
0.5s
151
P.232
10-21
Dwell frequency at
deceleration
0～650.00Hz
1.00Hz
151
P.233
10-22
Dwell time at deceleration
0～360.0s
0.5s
151
P.234
10-23
Triangular wave function
selection
0: Off.
0
152
1: If terminal function TRI is triggered, triangular
wave function will on.
2: Triangular wave function is on at all time.
P.235
10-24
Maximum amplitude
0～25.0%
10.0%
152
P.236
10-25
Amplitude compensation at
deceleration
0～50.0%
10.0%
152
P.237
10-26
Amplitude compensation at
acceleration
0～50.0%
10.0%
152
P.238
10-27
Amplitude acceleration time
0～360.00s/0～3600.0s
10.00s
152
P.239
10-28
Amplitude deceleration time
0～360.00s/0～3600.0s
10.00s
152
P.240
02-07
Auxiliary frequency
0: Off
0
79
2: Output frequency = basic frequency + auxiliary
frequency (given by terminal 3-5)
4: Output frequency = basic frequency - auxiliary
frequency (given by terminal 3-5)
6: Output frequency = proportional linkage signal
(given by terminal 3-5)
