Appendix 1 Parameter table
Appendix 178
DC brake before inverter start
1: Before starting operate DC brake first.
DC brake time before inverter start
DC brake voltage before inverter
start
7.5K/11KF and below model:0~30.0%
11K/15KF and above model:0~30.0%
0:When running turn on the fan, after stop for
30 seconds turn off the fan.
1:When power on turn on the fan, after
power off turn off the fan.
2:When running and the heat sink
temperature exceeds 60℃ turn on the fan,
under 40℃ turn off the fan.
3:When the heat sink temperature exceeds
60℃ turn on the fan, under 40℃ turn off the
fan.
PID pressure range (Bar) setting
Analog signal feedback loss
detection time
Analog signal feedback loss action
selection
0:Alarm AErr and inverter stop freely
1:Slow down to stop then alarm AErr
2:Alarm AErr and continue operation
S curve time at the beginning of
acceleration
S curve time at the end of
acceleration
S curve time at the beginning of
deceleration
S curve time at the end of
deceleration
Speed display unit selection
0: Speed display unit is 1
1: Speed display unit is 0.1
Action when detect over torque
0: OL2 alarm will not be reported after over
torque detection, and inverter keeps running.
1: OL2 alarm will be reported after over
torque detection, and inverter stops.
Maintenance alarm function
1~9998day: Used to set the time for
maintenance alarm output signal
