Shihlin electric SC3 Series User Manual

Appendix 5 Optional equipment
Appendix 207
 DU08 outline:
<Outline dimensional drawing>
< Panel mounting hole size >< Flange mounting hole size >
Note: For flange installation, the fixed installation base is not standard and needs to be purchased
separately, order code: SNKDUMH02 (DU08S already includes this fixed installation base).
2-M3
66.0
6.0
30.0
15.0
9.9
37.7
14.4
60.0
78.0
30.0
66.0
63.0
-
20.3
17.3
29.0
20.3
15.0
