System parameter group 00
PARAMETER DESCRIPTION 51
Group
No.
Name
00-21
P.300
Motor control mode selection
02-25
P.198
Terminal 3-5 minimum input current/ voltage
02-26
P.199
Terminal 3-5 maximum input current/ voltage
02-27
P.196
Percentage corresponds to terminal 3-5 minimum input current/ voltage
02-28
P.197
Percentage corresponds to terminal 3-5 maximum input current/ voltage
02-61
P.141
Polarity of percentage corresponds to terminal 3-5 current/ voltage signal
05-00
P.301
Motor specifications automatic measurement
05-01
P.302
Motor rated power
05-02
P.303
Motor poles
05-03
P.304
Motor rated voltage
05-04
P.305
Motor rated frequency
05-05
P.306
Motor rated current
05-06
P.307
Motor rated rotation speed
05-07
P.308
IM Motor excitation current
05-08
P.309
IM motor stator resistance
11-00
P.320
Slip compensation gain
11-01
P.321
Torque boost filter coefficient
5: User registered parameter 15-00~15-19(P.900~P.919) and the parameters set in 15-00~15-19(P.900~P.919)
and the parameters in table 1 above will not be restored to default values. After parameters are restored,
00-02(P.996~P.999) is reset to 0.
6: User registered parameter 15-00~15-19(P.900~P.919) and the parameters set in 15-00~15-19(P.900~P.919)
and the parameters in table 1 and table 2 above will not be restored to default values. After parameters are
restored, 00-02(P.996~P.999) is reset to 0.
Note: When the parameter is restored to default value or some of the parameters are restored to default value, be
sure to wait for the screen to display , which means that its complete, and then perform other
operations.
