Shihlin electric SC3 Series User Manual

Basic Parameter Group 01
PARAMETER DESCRIPTION 70
01-12(P.14)＝4
0
01-10
P.0
01-26(P.98)
01-28(P.162)
01-30(P.164)
01-32(P.166)
01-34(P.168)
01-27
P.99
01-35
P.169)
01-33
P.167
01-31
P.165
01-29
P.163
01-04
P.19
01-03(P.3)
Output voltage
%
Output frequency
Hz
Determine whether the curve is high starting torque or decreasing
torque according to the value of the parameter set in the figure (Note
1).
01-12(P.14)=5
01-10
P.0
0
A
3.00.1
100%
01-03
P.3
Output voltage
%
Output frequency
Hz
When 01-12(P.14)=5, the value of A is 7.1% (Note 2)
01-12(P.14)＝6，7，8
01-10
P.0
0
A
3.0
0.1
100%
01-03
P.3
Output voltage
%
Output frequency
Hz
When 01-12(P.14)=6, the value of A is 8.7%. When 01-12(P.14)=7, the
value of A is 10.4%. When 01-12(P.14)=8, value of A is 12.0%.(Note 2)
01-12(P.14)＝9，10
01-10
P.0
0
A
300.1
100%
01-03
P.3
Output voltage
%
Output frequency
Hz
When 01-12(P.14)=9, the value of A is 20.0%. When 01-12(P.14)=10,
the value of A is 25.0%.(Note 2)
01-12＝11，12，13
01-10
(P.0)
0
A
60.1
100%
01-03
(P.3)
Output voltage
%
Output frequency
Hz
When 01-12(P.14)= 11, the value of A is 9.3%. When01-12(P.14) = 12,
the value of A is 12.7%. When 01-12(P.14) = 13, the value of A is
16.1%. (Note 2)
Note: 1. Referring to the diagrams above, set 01-26(P.98) and 01-27(P.99) if one point is needed. Set 01-26(P.98),
01-27(P.99), 01-28(P.162) and 01-29(P.163) if two points are needed. 01-26(P.98), 01-27(P.99),
01-28(P.162), 01-29(P.163), 01-30(P.164) and 01-31(P.165) if three points are needed.
2. When set 01-12(P.14) between 5 and 13, if 01-10(P.0) is larger than the point A, point A equals to 01-10(P.0).
