When Data Length Exceeds the Standard Format
When data including stability information is output
Codes expressing S or U will be added to the head of the data. The
data length will therefore become one byte longer.
When “C/R+L/F” has been selected as the delimiter
Two bytes are required for delimiter information.
One byte will be added after the standard position 13. The data
length will therefore become one byte longer.
Verified balance as a legal measuring instrument
The brackets “[ ]” bordering auxiliary indicating device of legal measuring instrument are also
outputted. In this case, “[” and “]” are inserted to border the part of auxiliary indicating device
in the format. Consequently, the data becomes 2 bytes longer.
When [OL (Overload)] or [-OL (Overload)] is Output
The data format is as follows when [OL (Overload)] is output.
The data length in this example is 13 bytes.
Position
1 2 3 4 5 6 7 8 9 10 11 12 13
ASCII Code 20H 20H 20H 20H 20H 4FH 4CH 20H 20H 20H 20H 20H 0DH
Data O L C/R
A minus mark [-] (ASCII code: 2DH) will replace the space in position 1 when [-OL (Overload)] (negative
overload) is output.
List of Commands
Limitations on Balance Type and Status
The commands that can be used are restricted by the status and type of the balance.
Refer to the Shimadzu Corporation website for details.
Data Output
Command Function Remarks
D01
*2
Continual output Synchronized with the display update cycle (approximately 100msec)
and continually transmits weight data up until the D09 (cancel output)
command is received.
D02 Continual output when stable
D03 Continual output with stability
information
D04
*1
One-time enforced output Unconditionally performs one-time enforced output when the command is
received. ^ [Setting the Output timing] (P.14 4 )
D05
*2
One-time output Equivalent to the output key.
D06 Auto print setting Sets the auto print settings.
D07
*1
One-time output with stability
information
Unconditionally performs one-time output when stability information is
contained in the header and the command is received.
D08
*2
One-time output when stable Performs one-time output when the stability mark is illuminated after the
command has been received even when the output timing has been set at
[Immediately]. ^ [Setting the Output timing] (P.14 4)
D09 Cancel output Cancels continual output and the auto print settings.
*1 Not applicable to a verified balance as a legal measurement instrument in the EU.
*2 Output is not made when the display is not stable with a verified balance as a legal measuring instrument in the EU.
1 2 3 4
53H 2DH 20H 31H
S - 1
安定時のとき : S（53H）
不安定時のとき : U（55H）
1 2 3 4
53H 2DH 20H 31H
S - 1
When stable: S (53H)
When unstable: U (55H)
Position
ASCII code
Data
Position 1 11 12 13
ASCII code 2DH 20H 0DH 0AH
Data - C/R L/F
1 11 12 13
2DH 20H 0DH 0AH
- C/R L/F
*
To Next Page
