Shimadzu AP W-AD Series User Manual

88
The AP Series applications include the application function mode, the comparator function mode, and the
minimum weight value setting mode. Statistical calculation, the comparator function and minimum weight value
(MW) setting can also be used in combination when in the application measurement mode. The application
function is a mode for changing the settings and measurement methods for the purpose of weighing samples in
accordance with the sample type and environment. ^ [Application Function Mode] (this page)
Statistical calculation calculates the statistic for measurement values to produce average values, standard
deviation values, maximum values and minimum values, etc.
^ [Performing Statistical calculation (Statistical calculation)] (P.117)
The comparator function is a function that finds a difference between the weighing values and the reference
values or target values.
^ [Comparator Function] (P.118)
Minimum weight (MW) setting is a function for evaluating [Minimum Weight Values] in order to inform the user
of the range that measurements can be safely carried out.
^ [Minimum Weighing Value Mode] (P.122)
Application Function Mode

Application Function Mode
The regular measurement mode is known as the Standard measurement mode, There is also an
application function mode that is useful to match the sample type and environment or conditions. The
application function mode contains the modes listed below. It is possible to select one of these modes
to use in accordance with the method of application.
Switching between the Standard measurement Mode and the Application Weighing Mode
It is possible to switch across to the general measurement mode when measuring weight by
pressing [ DOWN].
However, it is not possible to switch modes when using the Statistical calculation, comparator
or minimum weight value (MW) setting functions.
List of application measurement mode functions
Functions that can be
used together
Icon Function Details
Statistics Comparator
Minimum
Weight
Piece counting
measurement
Enables the unit weight of the sample to be set so that the set number can be weighed.
^ [Measuring Part Quantities (Piece counting measurement)] (P.89)
  
Percent
measurement
Enables the percentage in relation to the standard weight to be weighed. ^ [Measuring
Percentages (Percent measurement)] (P.92)
  
Averaging mode
Enables fluctuations in the weighing value to be restrained when weighing moving
samples such as small animals or in bad conditions with strong vibrations, etc.
^ [Measuring Averages (Averaging mode)] (P.95)
  
Solid specific gravity
By weighing samples in air and in water, their specific gravity will be calculated.
^ [Measuring the Specific Gravity of Solids (Solid specific gravity)] (P.99)
  
Liquid density
By weighing samples in air and in water, their density will be calculated. ^ [Measuring
Liquid Density (Liquid density)] (P.103)
  
Add-on mode
Enables multiple samples to be weighed and the data for each sample to be output,
and creating records and adding the results at the same time. This mode is used when
formulating multiple samples. ^ [Measuring Large Quantities of Fine Samples (Add-on
mode)] (P.106)
× ×

Formulation mode
This is used to formulate multiple different samples. ^ [Measuring Formulas
(Formulation mode)] (P.108)
× ×

Recipe preparation
(W-AD/ W Series
only)
Enables pre-registered recipes to be called out and samples prepared in accordance
with that recipe. This is useful for compounding medicine.
^ [Preparing Samples in Accordance with Recipes (Recipe preparation) (W-AD/ W
Se r i es o n ly ) ] (P.111)
× ×

Buffer solution
preparation (W-AD/
W Series only)
A function for adjusting the buffer solution that has been registered for use with liquid
chromatographs or other analysis equipment in accordance with recipes.
^ [Buffer solution preparation (Preparing Buffer Solutions) (W-AD/ W Series only)]
(P.114)
× ×

Sample preparation
(W-AD/ W Series
only)
A function for supporting sample acquisition when preparing samples to be analyzed
with liquid chromatographs or other analysis equipment.
^ [Sample preparation for Analysis (Sample preparation) (W-AD/ W Series only)]
(P.115 )
× ×

*
77 ApplicationsApplications
