Shimadzu AP W-AD Series User Manual

17
11 SetupSetup
1
3
5
2
4
6
7
8
12
14
13
9
10
11
Inspecting the Contents of the Package
Check to ascertain that the following parts are included in the package, and that none of them are damaged.
The figure in parenthesis ([ ]) represents the quantity. Contact a Shimadzu sales office of representative
agency if any abnormalities are found.
Connecting Cable for Ionizer [1]
Cleaning brush for Ionizer [1]
AC cable for Ionizer [1]
POWER
ION
ALARM
Power pack [1]
◆ Only semi-micro models
Stage [1] Shield
Case [1]
Multi stand [1] AP Holder [1]
(AP225W-AD only)
Adjustable
Windbreak Plate [1]
Pan for fixing the
multi-stand [1]
Main balance unit [1] Pan [1] Shield plate [1]
Pan supporter [1]
Protection Cover [1] Adapter cable
holder [1]
Glass draft shield
(Right) [1]
AC adapter for
Balance [1]
Glass draft shield
(Left) [1]
* Excluding semi-micro models*Attached to balance main body.
Glass draft shield (Top) [1] AC adapter for Ionizer [1]
Insert card [1]
Instruction
manual [1]
stopper knob [3]
[W-AD Series]
[W/X/Y Series]
Power pack [1]
◆ Only semi-micro models
Stage [1] Shield Case [1] Multi stand [1] AP Holder [1]
(AP225W-AD only)
Pan for fixing the
multi-stand [1]
Main balance unit [1] Pan [1]
Shield plate [1]
Pan supporter [1]
AC adapter [1]
Protection Cover [1]
Adapter cable
holder [1]
* Excluding semi-micro models
* Excluding semi-micro models
Insert card [1] Instruction manual [1]
*Attached to balance main body.
FUNC
g
d
OK
