Useful Output Functions
Automatic Printing/Output (Auto-Print)
It is possible to output the weighing values displayed
automatically without pressing the [ PRINT] key for each
measurement.
When the auto print function is set at ON,
(auto print
mark) will be displayed at the bottom of the screen.
Cannot be Used in Combination with the Interval
Timer Function
The auto print function cannot be used in combination
with the interval timer function.
1. Call out the auto print function
(1) Press [ PRINT] for three or more consecutive seconds.
(2) Select [Print], press [ OK], and then Select [Auto Print] and then press [ OK].
Calling Out the Auto Print Function from [MENU]
Press [ MENU], select [
System settings], press [ OK], select [Print], press [ OK],
select [Auto Print], and then press [ OK]. This will perform the same operations.
2. Set auto print to ON or OFF
Select [on] or [off], and then press [ OK].
· Proceed to Step if [on] has been selected.
· End operations if [off] has been selected.
3. Select the Output timing conditions
(1) Select [Setting], and then press [ OK].
(2) Select either [Stabilize at Positive Value], [Stabilize at Negative Value], [Stabilize at Zero] or
[Pass for Pass/fail evaluation], and then press [ OK].
(3) Select [on] or [off], and then press [ OK].
[Output timing List]
Timing Details
Stabilize at Positive Value Automatically output once when a sample has been placed on the pan with a stable status
close to zero and stability detected at a positive value. If the sample is then removed or [O/T]
pressed, it is not possible to output the next value unless a return to zero has been determined.
Stabilize at Negative
Value
Automatically output once when a sample has been placed on the pan, [O/T] pressed,
stability detection carried out with zero, the sample removed, and stability detected at a
negative value. If the sample is then removed or [O/T] pressed, it is not possible to output
the next value unless stability detection with zero has been carried out.
Stabilize at Zero Automatically output once when a sample has been placed on the pan and stability
detection carried out, and stability detected at zero.
Pass for Pass/fail
evaluation
Automatically output once when stability is detected with the pass mark at [OK] in the Pass/
fail evaluation mode.
Return to zero
determined
See Step 4 below
[Zero] Return to zero determined once the value has stabilized close
to zero.
Use this setting if the priority is to be placed on weight
accuracy.
[50% of Previous Output] Return to zero determined if a weight value that is 50% of the
previous output is detected.
Use this setting if the priority is to be placed on work
efficiency (speed).
Auto Print Mark
The auto print mark will be
reverse displayed during output
*
*
To Next Page
