SICK EtherCAT microScan3 User Manual

►
S
elect scan cycle time.
✓
The resulting response time and the range of the fields are shown.
Additional interference protection
If y
ou mount several safety laser scanners in close proximity to each other, this can
lead to mutual interference. You will prevent mutual interference in neighboring safety
laser scanners if you choose different settings for interference protection.
Modes 1 to 4 are available. Interference protection influences the scan cycle time and
therefore the response time.
•
Mode1=+0ms per scan cycle
•
Mode2=+1ms per scan cycle
•
Mode3=+2ms per scan cycle
•
Mode4=+3ms per scan cycle
►
Configure a different mode for each safety laser scanner that is mounted in close
proximity.
✓
The resulting response time is shown.
Complementary information
NOTE
T
he response time of the safety laser scanner depends on the scan cycle time, interfer‐
ence protection, and multiple sampling, see "Response times", page 166. In addition
to the response time of the safety laser scanner, further signal transmission and
processing also influence the time until the end of the dangerous state.
A graphic shows how the configuration affects the available ranges.
7 C
ONFIGURATION
102
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
