SICK EtherCAT microScan3 User Manual

15 Spare parts
15.1 Safety laser scanner without system plug
Table 66: Safety laser scanner without system plug
Spare part for Type code Part number
Device Part number Protective field
ran
ge
microScan3 Core –
E
therCAT®
1108230 ≤4.0m MICS3-ABAZ40EN1 1108231
microScan3 Core –
EtherCAT®
1108232 ≤5.5m MICS3-ABAZ55EN1 1108233
microScan3 Core –
EtherCAT®
1108234 ≤9.0m MICS3-ABAZ90EN1 1108235
microScan3 Pro –
EtherCAT®
1108226 ≤4.0m MICS3-CBAZ40EN1 1108227
microScan3 Pro –
E
therCAT®
1103950 ≤5.5m MICS3-CBAZ55EN1 1104317
microScan3 Pro –
EtherCAT®
1108228 ≤9.0m MICS3-CBAZ90EN1 1108229
15.2 System plug
Table 67: System plug
Spare part for Connection type Type code Part number
Device Part number
microScan3 – EtherCAT® 1108230,
1108232,
1108234,
1108226,
1103950,
1108228
M12, 4-pin, D-coded MICSX-BANNEZZZ1 2081021
15.3 Additional spare parts
Table 68: Additional spare parts
Part Part number
Optics cover (with seal and screws) 2073673
Cover plate, 91.8mm × 31.3mm (with screws) 2086094
SPARE PARTS 15
8025220/1L9Q/2023-08-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT®
189
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
