D
ata sheets and application examples
•
CAD files and dimensional drawings
•
Certificates (such as the EU declaration of conformity)
•
Guide for Safe Machinery. Six steps to a safe machine
•
Safety Designer (software for configuring safety solutions made by SICK AG)
1.5 Symbols and document conventions
The following symbols and conventions are used in this document:
Warnings and other notes
DANGER
Indic
ates a situation presenting imminent danger, which will lead to death or serious
injuries if not prevented.
WARNING
Indic
ates a situation presenting possible danger, which may lead to death or serious
injuries if not prevented.
CAUTION
Indic
ates a situation presenting possible danger, which may lead to moderate or minor
injuries if not prevented.
NOTICE
Indic
ates a situation presenting possible danger, which may lead to property damage if
not prevented.
NOTE
Hi
ghlights useful tips and recommendations as well as information for efficient and
trouble-free operation.
Instructions to action
►
T
he arrow denotes instructions to action.
1. The sequence of instructions for action is numbered.
2. Follow the order in which the numbered instructions are given.
✓
The check mark denotes the result of an instruction.
LED symbols
These symbols indicate the status of an LED:
o
The LED is off.
Ö
The LED is flashing.
O
The LED is illuminated continuously.
ABOUT THIS DOCUMENT 1
8025220/1L9Q/2023-08-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT®
