You need a cut-off path for every field in a field set. If the field sets have different sizes,
use t
he field set with the most fields as a guide.
Creating cut-off path and entering a name
1. Create a cut-off path for every field in the largest field set.
2. Enter a descriptive name for each cut-off path.
Assigning the number of the cut-off path in the process data object (PDO)
►
Select the desired number.
✓
The number is assigned to the cut-off path.
Restart behavior
You define the restart behavior for all network outputs in the Inputs and outputs window.
If needed, define a deviating restart behavior for one or several network outputs.
7.14.5 Assigning field sets
Overview
T
he field sets that have been created are listed in the Field sets area.
Procedure
A
ssign a field set to a monitoring case
►
Assign a field set to a monitoring case using drag and drop.
✓
The fields in a field set are arranged as they were drawn in the field editor.
Assigning a field to a monitoring case
1. Assign a field set to a monitoring case using drag and drop.
2. Right click on the assigned field set and select Split fieldset.
3. Assign the individual fields to one or various monitoring cases.
Removing assignment
►
Drag a field set or field from a monitoring case onto the trash can icon.
7.14.6 Assigning a defined cut-off behavior
Overview
In a
monitoring case, you can assign a defined cut-off behavior to a cut-off path
instead of a field:
•
Always OFF: If the monitoring case becomes active, the cut-off path is in the OFF
state.
•
Always ON (NON-safe): If the monitoring case becomes active, a safety output in the
cut-off path is always in the OFF state. A non-safety output is always in the ON
state.
•
Always ON (safe): If the monitoring case becomes active, the cut-off path is in the ON
state.
Important information
DANGER
H
azard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of
non-observance.
The Always ON (safe) function has the same effect as a field which is always clear. In
a monitoring case with the Always ON (safe) function, the cut-off path containing this
function is permanently in the ON state.
7 CONFIGURATION
120
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice
