SICK EtherCAT microScan3 User Manual

13 Technical data
13.1 Variant overview
Ordering information:see "Or
dering information", page 188.
Table 27: Devices and type codes
Performance pack‐
a
ge
Integration in the
control
Protective field
range
Device without sys‐
tem plug
System plug Position of the
system plug
when delivered
Device with system
plug
•
C
ore
•
EtherCAT®
≤4.0m MICS3-ABAZ40EN1 MICSX-BANNEZZZ1 Bottom MICS3-ABAZ40EN1P01
≤5.5m MICS3-ABAZ55EN1 Bottom MICS3-ABAZ55EN1P01
≤9.0m MICS3-ABAZ90EN1 Bottom MICS3-ABAZ90EN1P01
•
Pr
o
•
EtherCAT®
≤4.0m MICS3-CBAZ40EN1 MICSX-BANNEZZZ1 Bottom MICS3-CBAZ40EN1P01
≤5.5m MICS3-CBAZ55EN1 Bottom MICS3-CBAZ55EN1P01
≤9.0m MICS3-CBAZ90EN1 Bottom MICS3-CBAZ90EN1P01
13.2 Version numbers and functional scope
Functional scope
Older devices might not support the full functional scope of the latest Safety Designer.
To identify the different levels of the functionality, we use a 3-digit version number. The
version number is marked with the letter V on the device.
The functional scope of the device can be read at the following locations:
•
Label on the device
•
Display, entry in Device info menu at Hardware
•
Safety Designer, Overview dialog (only with connected device)
•
Safety Designer, report
Table 28: microScan3 Core – EtherCAT® functional scope
Version number Amendments and new functions
V 1.0.0
•
First released version
V 1.1.0
•
New rights management using user group Administrator (now 4
user groups)
•
Additional third option for resetting to factory settings
•
Modified process for resetting the password
•
Deviating multiple sampling after object detection can be con‐
figured
•
Interfaces and selected functions can be activated or deacti‐
vated
•
New Always ON (NON-safe) function in monitoring case tables
Table 29: microScan3 Pro – EtherCAT® functional scope
Version number Amendments and new functions
V 1.0.0
•
F
irst released version
TECHNICAL DATA 13
8025220/1L9Q/2023-08-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT®
159
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
