EtherCAT (EoE) CoLa 2 (Device configuration and diagnosis)
T
he CoLa2 interface enables device configuration and diagnostics with Safety Designer
via network. For information on further functions of the CoLa2 interface, refer to the
technical information “microScan3, outdoorScan3, nanoScan3: Data output via UDP
and TCP/IP” (part number 8022706).
As soon as the interface is deactivated, no new connections can be established. An
existing connection remains open until it is closed or the timeout expires.
Ethernet Port 1
Y
ou can activate or deactivate the network connection.
Ethernet CoLa 2 (Device configuration and diagnosis)
T
he CoLa2 interface enables device configuration and diagnostics with Safety Designer
via network. For information on further functions of the CoLa2 interface, refer to the
technical information “microScan3, outdoorScan3, nanoScan3: Data output via UDP
and TCP/IP” (part number 8022706).
As soon as the interface is deactivated, no new connections can be established. An
existing connection remains open until it is closed or the timeout expires.
7.21.5 Optics cover calibration
Overview
Af
ter replacing an optics cover, the measurement system of the safety laser scanner
must be calibrated to the new optics cover. During optics cover calibration, the refer‐
ence for the contamination measurement of the optics cover is defined (status = not
contaminated).
Important information
WARNING
Incor
rect reference value of optical properties
If optics cover calibration is not done correctly, persons and parts of the body to be
protected may not be detected.
Carry out an optics cover calibration with the Safety Designer every time the optics
cover is replaced.
Carry out the optics cover calibration at room temperature (10°Cto30°C).
Only carry out the optics cover calibration using a new optics cover.
Before the optics cover calibration switch on the device for a few minutes to warm
up the internal components.
Make sure that the entire system is clear of contamination when the adjustment is
carried out.
Procedure
1.
Before the optics cover calibration, switch on the device for a few minutes to warm
up the internal components.
2. In the Exchange column, click on Yes.
3. Check that the optics cover is clean.
4. In the Check cleanliness column, click on OK.
5. In the Optical cover calibration column, click on Start.
The calibration process starts. Typically, this process can take up to a minute. A
progress bar shows the progress.
7 C
ONFIGURATION
130
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCA 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice
