The thorough check ensures the following:
•
C
ompliance with all relevant regulations and effectiveness of the protective device
for all of the machine’s operating modes. This includes the following points:
°
compliance with standards
°
correct use of the protective device
°
suitable configuration and safety function
°
correct alignment
•
The documentation matches the state of the machine, incl. the protective device
•
The verified configuration report corresponds to the desired project planning (see
"Verifying configuration", page 125)
The thorough checks must be carried out by qualified safety personnel or specially
qualified and authorized personnel and must be documented in a traceable manner.
In many cases, other data must be documented, see "Reports", page 127.
Recommended thorough checks
In man
y cases, it makes sense to carry out the following thorough checks during
commissioning and in certain situations:
•
Thorough check of the relevant points on the checklist, see "Checklist for initial
commissioning and commissioning", page 197
•
"Thorough visual check of the machine and the protective device", page 73
•
"Thorough check of the principal function of the protective device", page 71
•
"Thorough check of the area to be protected", page 71
•
"Test of the contour detection field", page 73
•
"Checking the collision protection field", page 73
•
Make sure that the operating personnel has been instructed in the protective
device’s function before starting work on the machine. The instruction is the
responsibility of the machine operator and must be carried out by qualified per‐
sonnel.
4.6.2 Planning the regular thorough check
Overview
T
he purpose of regular tests is to detect defects due to changes or external influences
(e.g. damage or manipulation) and to ensure that the protective measure provides the
necessary protection.
Important information
DANGER
H
azard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of
non-observance.
►
Carry out tests at least once a year.
►
Assign qualified safety personnel to carry out the tests or persons specifically
authorized for this purpose.
►
Document tests in a traceable manner.
Minimum requirements
T
he following thorough checks must be carried out at least once a year:
•
"Thorough check of the principal function of the protective device", page 71
•
Testing of the detection capability (resolution) in the context of the "Thorough
check of the area to be protected", page 71
4 P
ROJECT PLANNING
70
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice
