SICK EtherCAT microScan3 User Manual

The duration is specified as the number of consecutive scans in which an object is
de
tected in the field. For each duration, the diagram shows the corresponding number
of object detections.
11.4.3 Message history
Overview
Figure 90: Message history
1
Message history
2
Display filter
3
Details about the selected message
Events such as errors, warnings and information are stored in the message history.
B
y right-clicking on the table header, you can select the columns displayed in the
message history.
Safety Designer shows details about the events in the bottom part of the window, ways
to solve them are also shown.
Table 26: Print or export message history
Print message history
Save message history as a PDF
Save message history as CSV
11 TROUBLESHOOTING
156
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
