SICK EtherCAT microScan3 User Manual

1 About this document
1.1 Function of this document
These operating instructions contain the information needed during the life cycle of the
s
afety laser scanner.
Operating instructions of the safety laser scanner must be made available to all people
who work with the device.
Read the operating instructions carefully and ensure that you have understood the
contents completely before you work with the safety laser scanner.
1.2 Scope
Product
T
his document applies to the following products:
•
Product code: microScan3 – EtherCAT®
•
“Operating instructions” type label entry: 8025218
Document identification
Doc
ument part number:
•
This document: 8025220
•
Available language versions of this document: 8025218
You can find the current version of all documents at www.sick.com.
1.3 Target groups of these operating instructions
Some sections of these operating instructions are intended for certain target groups.
Ho
wever, the entire operating instructions are relevant for intended use of the product.
Table 1: Target groups and selected sections of these operating instructions
Target group Sections of these operating instructions
Project developers (planners, developers,
de
signers)
"Project planning", page 25
"Configuration", page 83
"Technical data", page 159
"Accessories", page 190
Installers "Mounting", page 75
Electricians "Electrical installation", page 80
Safety experts (such as CE authorized repre‐
sent
atives, compliance officers, people who
test and approve the application)
"Project planning", page 25
"Configuration", page 83
"Commissioning", page 132
"Technical data", page 159
"Checklist for initial commissioning and com‐
missioning", page 197
Operators "Operation", page 135
"T
roubleshooting", page 148
Maintenance personnel "Maintenance", page 141
"T
roubleshooting", page 148
1.4 Further information
www.sick.com
T
he following information is available via the Internet:
1 A
BOUT THIS DOCUMENT
8
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
