SICK EtherCAT microScan3 User Manual

Version number Amendments and new functions
V 1.1.0
•
N
ew rights management using user group Administrator (now 4
user groups)
•
Additional third option for resetting to factory settings
•
Modified process for resetting the password
•
Deviating multiple sampling after object detection can be con‐
figured
•
Collision protection field (devices with max. protective field
range 9 m)
•
Interfaces and selected functions can be activated or deacti‐
vated
•
New Always ON (NON-safe) function in monitoring case tables
Revision
T
he different revision statuses of the devices are identified by “Rev” followed by a three-
digit version number. New devices have a label which indicates the revision status.
Table 30: Revision
Version number Amendments and new functions
Rev 1.2.0
•
F
irst released version
Rev 1.3.0
•
Data output: Accuracy of angle specification improved
•
Adaptation of detection behavior for optimized safety and avail‐
ability
Rev 1.4.0
•
Internal change to components, no change in function
Rev 1.5.0
•
Int
ernal change to components, no change in function
Rev 1.6.0
•
Internal change to components, no change in function
13.3 Data sheet
13.3.1 microScan3 – EtherCAT®
Features
T
able 31: Features
 microScan3 Core – Ether‐
C
AT®
microScan3 Pro – EtherCAT®
Protective field range
Devices with a max. protec‐
tive field range of 4.0m
≤ 4.0m, details: see "Sensing range", page 168
Devices with a max. protec‐
tive field range of 5.5m
≤ 5.5m, details: see "Sensing range", page 168
Devices with a max. protec‐
t
ive field range of 9.0m
≤9.0m, details: see "Sensing range", page 168
Scanning range of the refer‐
ence contour field
Same as protective field range, see "Sensing range", page 168
Scanning range of the con‐
t
our detection field
Same as protective field range, see "Sensing range", page 168
Warning field range
Devices with a max. protec‐
tive field range of 4.0m
≤40m
Devices with a max. protec‐
t
ive field range of 5.5m
≤40m
13 TECHNICAL DATA
160
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
