SICK EtherCAT microScan3 User Manual

 microScan3 Core – Ether‐
C
AT®
microScan3 Pro – EtherCAT®
Devices with a max. protec‐
tive field range of 9.0m
≤64m
Distance measurement range
Devices with a max. protec‐
t
ive field range of 4.0m
≤40m
Devices with a max. protec‐
tive field range of 5.5m
≤40m
Devices with a max. protec‐
t
ive field range of 9.0m
≤64m
Fields ≤8 ≤128
Simultaneously monitored fields
Devices with a max. protec‐
t
ive field range of 4.0m
≤4 ≤8
Devices with a max. protec‐
tive field range of 5.5m
≤4 ≤8
Devices with a max. protec‐
t
ive field range of 9.0m
≤4
Simultaneous cut-off paths
Devices with a max. protec‐
tive field range of 4.0m
≤4 ≤8
Devices with a max. protec‐
t
ive field range of 5.5m
≤4 ≤8
Devices with a max. protec‐
tive field range of 9.0m
≤4
Field sets ≤8 ≤128
Monitoring cases ≤8 ≤128
Scanning angle 275° (–47.5° to 227.5°)
Protective field resolution 30mm, 40mm, 50mm, 60mm, 70mm, 150mm, 200mm
1)
Angular resolution
Devices with a max. protective field range of 4.0m
Scan cycle time 30ms 0.51°
Scan cycle time 40 ms 0.39°
Devices with a max. protective field range of 5.5m
Scan cycle time 30ms 0.51°
Scan cycle time 40 ms 0.39°
Devices with a max. protective field range of 9.0m
Scan cycle time 40 ms 0.125°
Scan cycle time 50ms 0.1°
Response time
Devices with a max. protec‐
t
ive field range of 4.0m
≥ 95ms, details: see "Response times", page 166
Devices with a max. protec‐
tive field range of 5.5m
≥ 95ms, details: see "Response times", page 166
Devices with a max. protec‐
tive field range of 9.0m
≥115ms, details: see "Response times", page 166
Scan cycle time
TECHNICAL DATA 13
8025220/1L9Q/2023-08-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT®
161
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
