SICK EtherCAT microScan3 User Manual

 microScan3 Core – Ether‐
C
AT®
microScan3 Pro – EtherCAT®
At 5.5m distance 2mm × 18mm
At 9.0m distance 11mm × 27mm
Devices with max. protective field range 5.5m
At front screen 18mm × 4mm
At 4.0m distance 5mm × 11mm
At 5.5m distance 2mm × 18mm
At 9.0m distance 11mm × 27mm
Devices with max. protective field range 9.0m
At front screen 18mm × 4mm
At 4.0m distance 8mm × 14mm
At 5.5m distance 4mm × 19mm
At 9.0m distance 2mm × 30mm
Divergence of collimated
be
am
0.17°
Receiving angle 0.75°
Pulse duration typ. 4ns
Average output power 9.2mW
Laser class 1M
Measurement uncertainty
4)
Devices with max. protective
f
ield range 4.0m
Typ. ±25mm
Devices with max. protective
field range 5.5m
Typ. ±25mm
Devices with max. protective
f
ield range 9.0m
Typ. ±50mm
1)
In the event of heavy contamination, the safety laser scanner displays a contamination error and
s
witches all safety outputs to the OFF state.
2)
In close proximity (50mm-wide area in front of the optics cover), the detection capability of the safety
laser scanner may be restricted. If required, this area must be secured using an undercut or frame, for
example.
3)
W × H when the laser beam exits at a 90° angle to the front.
4)
Typical values at 20°C and remission factor = 1.8%, distance = protective field range.
The measured values are less accurate for reflectors or reflective surfaces because the distance meas‐
urement is designed for lower remission values.
Complementary information
F
or more technical data specifically relating to the measurement data, see the technical
information “microScan3, outdoorScan3, nanoScan3: Data output via UDP and TCP/IP”
(part number 8022706).
13.4 Response times
The protective device’s response time is the maximum time between the occurrence of
t
he event leading to the sensor’s response and supply of the switch-off signal to the
protective device’s interface (for example OFF state of the OSSD pair).
13 T
ECHNICAL DATA
166
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
