SICK EtherCAT microScan3 User Manual

 microScan3 Core – Ether‐
C
AT®
microScan3 Pro – EtherCAT®
Standards
•
IE
C 60068-2-6
•
IEC 60068-2-64
•
IEC 60721-3-5
•
IEC TR 60721-4-3
•
IEC 61496-1
•
IEC 61496-3
Class
•
5M1 (IEC60721-3-5)
•
3M4 (IECTR60721-4-3)
Sinusoidal vibrations
•
50m/s², 0.35mm, 10Hz … 150Hz
•
5m/s², 1.5mm, 5Hz … 200Hz
•
10m/s², 3.5mm, 5Hz … 150Hz
Noise vibrations
•
0.5m²/s³, 5Hz … 200Hz
•
0.1m²/s³, 200Hz … 500Hz
Shock resistance
4)
Standards
•
IE
C 60068-2-27
•
IEC 60721-3-5
•
IEC TR 60721-4-3
•
IEC 61496-1
•
IEC 61496-3
Class
•
5M1 (IEC60721-3-5)
•
3M4 (IECTR60721-4-3)
Single shock 50m/s², 11ms
Continuous shock
•
100m/s², 16ms
•
150m/s², 6ms
EMC In accordance with IEC61496-1, IEC61000-6-2, and
IE
C61000-6-4
1)
The specified enclosure rating is only valid if the safety laser scanner is closed, the system plug and the
co
ver plate are mounted, and all of the M12, RJ45 and SCRJ plug connectors of the safety laser scanner
have been closed using a cable plug connector suitable for the enclosure rating or using a protective cap.
2)
For ambient light sources directly in the scan plane in accordance with IEC61496-3: ≤3klx.
3)
IEC61496-1, no. 4.3.1and no. 5.4.2, IEC61496-3, no. 4.3.1 and no. 5.4.2. Condensation has an
influence on normal operation.
4)
For direct mounting.
Miscellaneous data
T
able 37: Miscellaneous data
 microScan3 Core – Ether‐
C
AT®
microScan3 Pro – EtherCAT®
Wavelength 845nm
Detectable remission 1.8% to several 1,000%
Maximum uniform contami‐
na
tion of the optics cover
without reducing the detec‐
tion capability
1)
30%
Area where detection capabil‐
it
y is restricted
≤50mm
2)
Light spot size
3)
Devices with a max. protective field range of 4.0m
At front screen 18mm × 4mm
At 4.0m distance 5mm × 11mm
TECHNICAL DATA 13
8025220/1L9Q/2023-08-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT®
165
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
