SICK EtherCAT microScan3 User Manual

Electrical data
T
able 34: Electrical data
 microScan3 Core – Ether‐
C
AT®
microScan3 Pro – EtherCAT®
Operating data
Protection class III (IEC 61140)
Supply voltage V
S
24VDC (16.8V to 30VDC) (SELV/PELV)
1)
Residual ripple ±5%
2)
Start-up current ≤3A
Current consumption at 24V
Operation ≤0.45A (typ. 0.3A)
Sleep mode typ. 0.29A
Power consumption
Operation ≤11W (typ. 7.2W)
Sleep mode typ. 7W
Power-up delay ≤45s (typ. 20s)
1)
The supply voltage must be within the specified range at all times. It must not fall below the lower limit,
e
ven for a brief period.
The power supply unit must be able to bridge a brief power failure of 20ms as specified in
IEC60204-1.Suitable power supply units are available as accessories from SICK.
2)
The voltage level must not fall below the specified minimum voltage.
Mechanical data
T
able 35: Mechanical data
 microScan3 Core – Ether‐
CAT®
microScan3 Pro – EtherCAT®
Dimensions (without system
plu
g, W × H × D)
112mm × 150.7mm × 111.1mm
Weight (including system
plug)
1.45kg
Housingmaterial Aluminum
Housing color RAL 9005 (black) and RAL 1021 (colza yellow)
Optics cover material Polycarbonate
Optics cover surface Outside with scratch-resistant coating
Ambient data
T
able 36: Ambient data
 microScan3 Core – Ether‐
C
AT®
microScan3 Pro – EtherCAT®
Enclosure rating
1)
IP65 (IEC 60529)
Ambient light immunity ≤40klx
2)
Ambient operating tempera‐
t
ure
–10°C … 50°C
Storage temperature –25°C … 70°C
Air humidity ≤95%, non-condensing
3)
Height above sea level during
oper
ation
≤2,300m
Vibration resistance
4)
13 TECHNICAL DATA
164
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
