SICK EtherCAT microScan3 User Manual

13.5 Sensing range
Protective field range
T
he effective protective field range depends on the variant, on the set scan cycle time
and on the set object resolution.
Table 39: Protective field range (devices with a max. protective field range of 4.0m)
Resolution Scan cycle time 40ms Scan cycle time 30ms
≥70mm 4.00m 4.00m
50mm 3.50m 3.00m
40mm 3.00m 2.30m
30mm 2.30m 1.70m
Table 40: Protective field range (devices with a max. protective field range of 5.5m)
Resolution Scan cycle time 40ms Scan cycle time 30ms
≥70mm 5.50m 4.00m
50mm 3.50m 3.00m
40mm 3.00m 2.30m
30mm 2.30m 1.70m
Table 41: Protective field range (devices with a max. protective field range of 9.0m)
Resolution 50ms scan cycle time 40ms scan cycle time
≥ 150mm 9.00m 9.00m
70mm 9.00m 7.00m
60mm 8.00m 6.00m
50mm 7.00m 5.00m
40mm 5.00m 4.00m
30mm 4.50m 3.00m
Scanning range of the reference contour field
T
he effective scanning range of the reference contour field is the same as the protec‐
tive field range.
Scanning range of the contour detection field
T
he effective scanning range of the contour detection field is the same as the protective
field range.
Range for warning fields
F
or non-safety applications (warning fields), the safety laser scanner has a larger scan‐
ning range than the maximum protective field range. The requirements for size and
remission factor of objects to be detected are illustrated in the following graphs as a
function of the desired scanning range.
13 T
ECHNICAL DATA
168
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
