SICK EtherCAT microScan3 User Manual

 microScan3 Core – Ether‐
C
AT®
microScan3 Pro – EtherCAT®
Devices with a max. protec‐
tive field range of 4.0m
30ms or 40ms (adjustable)
Devices with a max. protec‐
t
ive field range of 5.5m
30ms or 40ms (adjustable)
Devices with a max. protec‐
tive field range of 9.0m
40ms oder 50ms (adjustable)
Generally necessary protective field supplement (TZ = tolerance zone of the safety laser
scanner)
Devices with a max. protec‐
t
ive field range of 4.0m
65mm
Devices with a max. protec‐
tive field range of 5.5m
65mm
Devices with a max. protec‐
t
ive field range of 9.0m
100mm
Additional supplement
Z
R
for reflection-based meas‐
urement errors
350 mm
Deviation from ideal flatness
of sc
an field at 5.5m
2)
≤ ±100mm
Deviation from ideal flatness
of sc
an field at 9.0m
3)
≤ ±100mm
Distance of mirror rotational
axis (zero point of x and y
axis) to mounting surface on
rear side of device
56 mm
Distance between center
point of scan plane and top
edge of the housing
40 mm
Multiple sampling 2 … 16
4)
1)
Protective field resolution 60mm only available for devices with max. protective field range of 9.0m.
2)
Devices with a max. protective field range of 4.0m and devices with max. protective field range of 5.5m.
3)
Devices with a max. protective field range of 9.0m.
4)
Can be adjusted collectively for all fields or individually for each field.
Safety-related parameters
T
able 32: Safety-related parameters
 microScan3 Core – Ether‐
C
AT®
microScan3 Pro – EtherCAT®
Type Type 3 (IEC61496)
Safety integrity level SIL 2 (IEC61508)
SIL claim limit SILCL 2 (IEC62061)
Category Category 3 (ISO 13849-1)
Performance level PL d (ISO13849-1)
PFH
D
(me
an probability of a
dangerous failure per hour)
8 × 10
–8
T
M
(mis
sion time) 20years (ISO 13849-1)
Safe status when an error
oc
curs
The safety outputs via the network are logic 0.
13 TECHNICAL DATA
162
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
