Complementary information
NOTE
If t
he system plug has also been replaced, then the configuration must be transferred
to the safety laser scanner using the CDS. Acceptance by qualified safety personnel is
required in this case.
NOTE
T
o be able to unambiguously differentiate between the host device and the guest
device in an EFI system, one safety laser scanner must be configured as the guest.
If the system plug on a guest device has been replaced, the jumper must be rewired on
the guest device.
b
To define the guest device, wire a jumper between terminals 7 (A1 / INC1_0) and
13 (UNI-I/O3 / ERR/WEAK).
The jumper always defines the guest device. This jumper must not be fitted on the host
device.
Further topics
"Daily check of the protective device by authorized and specialist personnel",
page 107
"Error and status indications on the 7segment display", page 114
"Error and status indications of the LEDs", page 113
"Pin assignment", page 65
8 COMMISSIONING
106
O P E R A T I N G I N S T R U C T I O N S | S300 8010948/ZA21/2020-06-18 | SICK
Subject to change without notice
