Page #46 background imageLoading...
Page #46 background image
NOTE
T
he device must only be used to protect vehicles that are powered by an electric
motor.
Because the safety laser scanner itself is moving in a mobile application, a resolu‐
tion of 70 mm is sufficient for detecting people.
In the following calculations, only the vehicle speed is taken into account and not
the speed of a walking person. This is based on the assumption that the person
recognizes the danger and stands still.
If the application is to protect vehicles from collisions, then it may be necessary to
use different assumptions.
For a horizontally mounted mobile application, you determine the following:
Pr
otective field length
Protective field width
Height of the scan plane
Restart behavior
Measures to prevent unsecured areas
4.3.7.1 Protective field length
Overview
Y
ou must configure the protective field so that a minimum distance to the vehicle is
upheld. This minimum distance ensures that a vehicle monitored by the safety laser
scanner stops before a person or an object is reached.
If you use a S300 Advanced, Professional or Expert, you can define several monitoring
cases with different protective fields. These monitoring cases can be switching using
static control inputs or, in the case of the S300 Professional and Expert variants, also
dynamically.
In the case of dynamic switching, the S300 Professional and Expert use the incremen‐
tal encoders connected to them to determine the speed of the vehicle. The S300 Pro‐
fessional and Expert can therefore switch the protective field depending on the speed.
In such an application, you must calculate the protective field sizes (especially the pro‐
tective field lengths) for all speeds.
Protective field length S
L
C
alculate the protective field length S
L
using the following formula:
S
L
= S
A
+ Z
G
+ Z
R
+ Z
F
+ Z
B
where
S
A
= Stopping distance
Z
G
= General supplement = 100 mm
Z
R
= Supplement for a possible reflection-related measurement error of the safety
laser scanner
Z
F
= Supplement for a possible lack of ground clearance of the vehicle
Z
B
= Supplement for the decreasing braking force of the vehicle as specified in the
relevant vehicle documentation
Stopping distance S
A
T
he stopping distance comprises the vehicle’s braking distance and the distance cov‐
ered during the safety laser scanner’s response time and the vehicle control’s response
time.
4 PROJECT PLANNING
46
O P E R A T I N G I N S T R U C T I O N S | S300 8010948/ZA21/2020-06-18 | SICK
Subject to change without notice
