External fan unit
5.2 Overview
SINAMICS S120 Combi
104 Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
5.2 Overview
The external fan unit comprises the following components:
● Fan cradle with seal for installation in the control cabinet
● Connection cables with 4-pin connector
● Double fan
● Fan support plate
● Air baffle plate
)DQFUDGOH
$LUEDIIOHSODWH
'RXEOHIDQ
6HDO
&RQQHFWLQJFDEOHZLWK
SLQFRQQHFWRU
Figure 5-1 External fan unit
When a fan fails, the complete external fan unit must be replaced.
