Siemens SINAMICS S120 Combi User Manual

System overview
1.2 System data
SINAMICS S120 Combi
Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
23
1.2 System data
Technical data
The following technical data apply for SINAMICS S120 Combi Power Modules.
Table 1- 1 Electrical data
Line connection voltage 3-ph. 380 V AC -10 % to 3-ph. 480 V AC +10 %
Above 2000 m installation altitude, refer to the characteristic
for voltage derating
Line frequency 45 Hz to 66 Hz
Line supply types TN, TT, and IT line supplies
Electronics power supply 24 V DC -15/+20 %
1)
,
Safety extra-low voltage DVC A (PELV)
Rated short-circuit current SCCR according to UL508C 10 kA
Radio interference suppression according to EN 61800-3 Category C2
for plant and system versions in conformance with the
documentation
Overvoltage category III according to EN 61800-5-1
Pollution degree 2 according to EN 61800-5-1
1) If a motor holding brake is used, restricted voltage tolerances (24 V ± 10 %) may have to be taken into account.
Table 1- 2 Environmental conditions
Degree of protection IP20 or IPXXB according to EN 60529,
open type in accordance with UL508
Protection class for line current circuits
Protection class for electronic circuits
I (with protective conductor connection) and
III (safety extra-low voltage DVC A / PELV) acc. to
EN 61 800-5-1
Permissible cooling medium temperature (air) and
installation altitude in operation
0 °C to +45 °C up to an installation altitude of 1000 m without
derating,
installation altitude >1000 °C up to 4000 m, see the derating
characteristic with respect to the installation altitude or
reduction of the ambient temperature by 3.5 K per 500 m.
Chemically active substances
Long-term storage in the transport packaging Class 1C2 according to EN 60721-3-1
Transport in the transport packaging Class 2C2 according to EN 60721-3-2
Operation Class 3C2 according to EN 60721-3-3
Biological environmental conditions
Long-term storage in the transport packaging Class 1B1 according to EN 60721-3-1
Transport in the transport packaging Class 2B1 according to EN 60721-3-2
Operation Class 3B1 according to EN 60721-3-3
